Inno3D GeForce RTX 4080 SUPER X3

GPU Engine Specs
CUDA Cores: 9728
Boost Clock (MHz): 2535WHz
Base Clock (MHz): 2205WHz

Thermal and Power Spec
Minimum System Power Requirement (W): 750W
Supplementary Power Connectors: 3x PCIe 8-pin cables (adapter in box) OR 320 W or greater PCIe Gen 5 cable

Memory Specs
Memory Clock: 22.4Gbps
Standard Memory Config: 16GB
Memory Interface: GDDR6X
Memory Interface Width: 256-bit
Memory Bandwidth (GB/sec): 716.8 GB/sec

Feature Support
Real-Time Ray Tracing: Yes
Ray Tracing Cores: 3rd Generation
Tensor Cores: 4th Generation
NVIDIA Architecture: Ada Lovelace
Microsoft DirectX: 12 Ultimate
NVIDIA DLSS: 3
PCI Express Gen 4: Yes
NVIDIA GeForce Experience: Yes
NVIDIA Ansel: Yes
NVIDIA FreeStyle: Yes
Bus Support: PCI-E 4.0 X16
NVIDIA ShadowPlay: Yes
OS Certification: Windows 11 / 10, Linux, FreeBSDx86
NVIDIA Highlights: Yes
NVIDIA G-SYNC™-Ready: Yes
Game Ready Drivers: Yes
NVIDIA Studio Drivers: Yes
NVIDIA GPU Boost: Yes
Vulkan API: Yes
OpenGL: 4.6
DisplayPort 1.4a: Yes
NVIDIA Encoder: 2x 8th Generation
NVIDIA Decoder: 5th Generation
HDMI 2.1a: Yes

Dimensions
Length: 328mm
Height: 137mm
Width: 62mm

Display Support
Multi Monitor: Yes
Maxmium Digital Resolution: 7680x4320
HDCP: 2.3
Standard Display Connectors: HDMI 2.1a, 3x DisplayPort 1.4a
