Intel Xeon W-1250P

Product Collection Intel® Xeon® W Processor
Code Name Products formerly Comet Lake
Segment: Workstation
Lithography 14 nm

Performance
# of Cores 6
# of Threads 12
Processor Base Frequency 4.1 GHz
Max Turbo Frequency 4.8 GHz
Cache 12 MB
TDP 125 W

Memory Specifications
Max Memory Size (dependent on memory type) 128 GB
Memory Type DDR4-2666
Max # of Memory Channels 2
ECC Memory Supported Yes

Processor Graphics
Processor Graphics  Intel® UHD Graphics P630
Base Frequency 350 MHz
Max Dynamic Frequency 1.20 GHz
Video Max Memory 64 GB
4K Support Yes, at 60Hz
Max Resolution (HDMI)‡ 4096x2160@30Hz
Max Resolution (DP)‡ 4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel) 4096x2304@60Hz
DirectX* Support 12
OpenGL* Support 4.5
Intel® Quick Sync Video Yes
Intel® InTru™ 3D Technology Yes
Intel® Clear Video HD Technology Yes
Intel® Clear Video Technology Yes
# of Displays Supported 3

Expansion Options
Scalability 1S Only
PCI Express Revision 3.0
PCI Express Configurations  1x16,2x8,1x8+2x4
Max # of PCI Express Lanes 16

Package Specifications
Sockets Supported FCLGA1200
Max CPU Configuration 1
TCASE 73°C
TJUNCTION 100
Package Size 37.5 mm x 37.5 mm

Advanced Technologies
Intel® Optane™ Memory Supported  Yes
Intel® Thermal Velocity Boost No
Intel® Turbo Boost Max Technology 3.0  No
Intel® Turbo Boost Technology  2.0
Intel vPro® Platform Eligibility  Yes
Intel® Hyper-Threading Technology  Yes
Intel® Virtualization Technology (VT-x)  Yes
Intel® Virtualization Technology for Directed I/O (VT-d)  Yes
Intel® VT-x with Extended Page Tables (EPT)  Yes
Intel® Transactional Synchronization Extensions No
Intel® 64  Yes
Instruction Set 64-bit
Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Thermal Monitoring Technologies Yes
Intel® Identity Protection Technology  Yes

Security & Reliability
Intel® AES New Instructions Yes
Secure Key Yes
Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® ME
Intel® OS Guard Yes
Intel® Trusted Execution Technology  Yes
Execute Disable Bit  Yes
Intel® Boot Guard Yes
