Teltonika TRB500 INDUSTRIAL 5G GATEWAY

The TRB500 gateway is a compact-sized and energy-efficient industrial gateway with a Gigabit Ethernet interface and two configurable I/Os, allowing high-level customization and implementation of a multitude of scenarios.

This device enables 5G network speeds with ultra-low latency for mission-critical infrastructures and high data throughput, ensured by 4 external antennas that allow the use of 4x4 MIMO.

TRB500 comes with the RutOS operating system, which provides advanced security features and compatibility with our Remote Management System (RMS) for optimized remote management and monitoring capabilities of large fleets of devices.


Technické parametry
Bezdrátové vlastnosti
Bezdrátové frekvence: 3G (GSM), 4G (GSM), 5G (GSM)
Podporované kanály 4G/LTE: (1) 2100 MHz, (3) 1800 MHz, (5) 850 MHz, (7) 2600 MHz, (8) 900 MHz, (20) 800 MHz, (28) 700 MHz, (32) 1500 MHz, (38) 2600 MHz, (40) 2300 MHz, (41) 2500 MHz, (42) 3500 MHz, (43) 3700 MHz, (77) 3700 MHz, (78) 3500 MHz
Podporované kanály 5G NR NSA: n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78
Podporované kanály 5G NR SA: n1, n3, n5, n7, n8, n20, n28, n38, n40, n41, n77, n78


Konektory a rozhraní
VF konektory: (4) SMA female
Rychlost LAN: (1) 10/100/1000Mbps
Slot na SIM kartu: Ano
Počet SIM slotů: 1

Napájení
Typ napájení: DC konektor
Max. spotřeba energie [W]: 6
Napájení přes konektor/svorkovnici: 9 .. 30V DC

Fyzické charakteristiky
Stupeň krytí: IP30
Provedení: Desktop, Na DIN lištu
Provozní teplota [°C]: -40 až 75
Hmotnost [g]: 241
Šířka [mm]: 100
Výška [mm]: 30
Hloubka [mm]: 93

Hardware
Interní uložiště [MB]: 512
RAM [MB]: 256

Software
Podporované VPN: PPTP, L2TP, IPSec, OpenVPN, WireGuard, ZeroTier, GRE
Operační systém: RutOS (OpenWrt based Linux OS)
